Specifications
Socket Type:Socket 754
Chipset:VIA K8T800 Chipset
Processor:AMD Athlon-64, Sempron
Max FSB:800MHz (Hyper-Transport)
Memory:2 x DDR SDRAM PC2700/3200, 2GB max.
AGP/VGA Slot:1 (8x, 4x mode @ 1.5v)
PCI Slot:5 (32-bit)
IDE:2 x E/IDE Ultra DMA/133, 4 drives max.
SATA:6 (2 by VT8237, 4 by Sil3114 with Raid 0, 1, 10 Support)
USB:8 (4 Rear, 4 Pin Header) USB 2.0
Network:Dual Lan (3COM 3C940 GbE + VIA VT6103)
Audio:Realtek ALC65X selectable 2 or 6-CH audio CODEC with SPDIF Out (RCA+Optical)
SPDIF:Yes
BIOS:Award/Phoenix BIOS v6.0
Power BIOS:Yes
LED Debug:P80P LED Debug Display
Size:ATX (305mm x 245mm)
Accessories: IDE/Floppy Cables, SATA Data/Power Cables, I/O Shield, CD Driver, Manual
